Specification
Operation Space | 24 inch |
Gauge | 15/18/20 |
Weft Bars | 3-8 Bars |
Inverter | 2 Hp |
Operating Motor | 1 Unit |
Finished Product Collecting Roller on both side | 1 Set |
Warp and Weft Reed | 1 Set |
Rubber Feeder System | 2 Sets |
Auto Stop Motion System | 2 Sets |
Creel For | 440 Bobbins(220 Bobbinx2) |
Net Weight of Machine | 850 kg |
Net Weight of Creel | 195 kg |
Crate of Machine | 210x115x180 /cm |
Crate of Creel | 250x40x45x /cm |
Weight of Machine and Crate | 1100 kg |
Weight of Crate and Creel | 235 kg |
